Figure 1E - Busbar Operating Mechanism

1, Spring cap. 2, Spring-cap bolt. 3, Spring-cap ball pin. 4, Spring-cap shim. 5, Busbar spring. 6, Spring guide (upper). 7, Spring guide (lower). 8, Busbar bucket. 9, Busbar operating shaft. 10, Operating lever (internal). 12, Busbar strut (upper). 13, Busbar strut (lower). 14, Retaing plate for strut (upper). 15, Tab washer. 16, Busbar operating lever (external). 17, Busbar operating-lever bolt. 18, Pedal connecting rod. 19, Fork end. 10, Fork-end pin.
